FUSEBOX RTAMB10BD 10AMP DOUBLE POLE B CURVE 6KA 30MA TYPE A MINI RCBO

Original price was: £40.33£48.40.Current price is: £15.27£18.32. Excl. VATIncl. VAT

Delivery

Collection

The FuseBox RTAMB10BD is a 10A double-pole Mini RCBO designed to provide exceptional protection against overload, short circuit, and earth leakage. With a 6kA breaking capacity and B curve tripping characteristics (3-5In), it operates at 230V AC with a 30mA residual operating current for enhanced safety. This RCBO is fully compliant with IEC 61009-1 standards, ensuring reliability for residential and light commercial installations. This compact RCBO fits perfectly into FuseBox consumer units, providing space-saving installation without sacrificing protection. The Type A sensitivity safeguards against both AC and pulsating DC faults, making it an ideal solution for various applications. The flying neutral cable and 1-16mm² terminal capacity simplify the installation process, offering enhanced convenience and efficiency.

Features

10A rated current for effective circuit protection.
6kA breaking capacity for short circuit and overload protection.
B curve tripping characteristics (3-5In) for fast response.
Type A RCBO detects both AC and pulsating DC faults.
Operates at 230V AC, 50/60Hz frequency.
30mA residual operating current (IΔn) for earth leakage protection.
2-pole configuration with switched line and neutral.
Flying neutral cable for easier installation.
IP20 protection degree, suitable for indoor use.
Compliant with IEC 61009-1 and IEC 61009-2-2 standards.
1-16mm² terminal capacity for flexible wiring.
Compact design for space-saving installation in consumer units.
Fits standard 35mm DIN rail
Colour / Finish White
